. Quick Installation.3 Before Installation.3 Layout.4 Item Checklist.4 Jumpers/ Connectors.5 Feature. 10 Motherboard Components Placement.10 Block Diagram.12 Specifications.13 Hardware Setup.15 Install the Processor.15 Install Memory Modules.17 ATX Power Supply Connector.18 Back Panel.19 FB0 mP4S Version 1.0A. Advanced BIOS Features.26 Advanced Chipset Features.29 Integrated Peripherals.31 Power Management Setup.36 PnP/ PCI Configurations.40 PC Health Status.42 IWILL Smart Setting.42 Load Fail Safe Defaults.44 Load Optimized Defaults.44 Set Supervisor/ User Password Setting.45 Save & Exit Setup.46 Exit Without Saving.46 On board Audio. Chapter 1 Quick Installation Quick Installation Before Installation For installation, you may need some or all of the following tools: Medium size flat blade screwdriver Medium size Phillips head screwdriver A 3/16 inch nut driver or wrench o l l n i l a l l o i t.
ATA 100/66 IDE cable V Floppy cable V Power Installer CD V 6CHG (6 channel audio bracket) V 6CH1394 (1394 bracket, mP4S-1394 only) Optional USB riser kit IWILL Super Audio (for SPDIF). Chapter 1 Quick Installation Jumpers/Connectors PS2SB Disabled Enabled mPGA478B (Default) Flash Protect jumper Control by BIOS Flashable Protected by H/W (Default) Clear CMOS Clear CMOS Normal (Default) LAN Setting mPGA478B 1 2 3 1 2 3 Enabled Disabled (Default) Audio Jumper 1 2 3 1 2 3 Enabled. Chapter 1 Quick Installation mPGA478B CPU Fan System Fan Auxiliary Fan PIN Assignment 1: GND 2: 12V 3: Sensor SMBus connector PIN Assignment 1: SMBUSCLK mPGA478B 2: NC 3: GND 4: SMBDATA 5: VCC Infrared connector (IR) 6 7 8 9 10 PIN Assignment 1: 5V 6: NC. AuxIn/ CDIn Connector mPGA478B 1 2 3 4 PIN Assignment 1: Left Channel 2: GND 3: GND 4: Right Channel SPDIF & IWILL 6CH bracket PIN Assignment 1: +12V 2:NC 3: NC 4: SPDIFO 5: SPDIFI 6: GND 7: NC. Chapter 1 Quick Installation ATX power connector ATX connector mPGA478B i n i o i t i n i o i t. Chapter 1 Quick Installation Front panel connector Front panel connector Front panel connector Front panel connector Front panel connector mPGA478B Front Panel. Chapter2 Feature Features Motherboard Components Placement mPGA478B.
Chapter2 Feature ) n i l e t t o l, t u l e l. Chapter2 Feature Block Diagram Socket 478 CPU i845 Chipset AGP 4X SDRAM (North Bridge) PCI x 2 SM Bus ICH2 82801BA IDE Channel x 2 6 Channel sound (South Bridge) Keyboard & Mouse 2xUSB Ports Internal USBx2 Super I/O Serial Port x 2 H/W Monitoring Infrared Port Parallel Port.
Chapter2 Feature Specifications Processor / (Socket478) Supports single processor Supports 400M FSB ( Front Side Bus) Supports Intel Pentium 4 CPU from 1.4 to 2.0 GHz and higher. CPU Frequency/Voltage Selection Supports CPU Multiplier selection from BIOS Supports CPU External Frequency selection from BIOS Memory Supports PC100/PC133 SDRAM Supports ECC DIMMs. Chapter2 Feature Management Supports voltage monitoring (+12V/-12V/+5V/-5V/Vcore/Vcore2/VTT/VIO/Vbat/Vsb) Supports fan control signal (CPU/AUX/SYS1) Supports temperature sensor (CPU/AUX/SYS) Supports Chassis Intrusion Supports Power on by LAN/Ext. Modem/PS2 Keyboard/ PS2 Mouse/RTC/PME Supports Resume by LAN/Ext.
Modem/PS2 Keyboard/ PS2 Mouse/RTC/PME Supports ACPI Supports APM Supports DMI Supports SMBUS. Chapter 3 Hardware Setup Hardware Setup Intel Pentium 4 Processor Installation Procedure The motherboard comes with a surface mount 478-pin ZIF socket. This socket is specifically designed for Intel Pentium 4 478 processor. Install the processor retention mechanism following the illustration. Chapter 3 Hardware Setup CPU Cooler and heatsink Installation Notes The Intel Pentium 4 processor requires a specially designed heatsink and fan assembly to ensure optimum thermal condition and performance.
The heatsink may have thermal interface material attached to the bottom as shown in Fig. Chapter 3 Hardware Setup Install Memory Modules IWILL mP4S comes with PC133 memory module (DIMM) sockets. These sockets support up to 3GB system memory using unbuffered ECC or non-ECC PC133 memory. Make sure to unplug the power supply before adding or removing memory module. Chapter 3 Hardware Setup ATX Power Supply Connector Power on procedures o i t l l a o i t. F f t e l h t i n i t a t l o l l t i n l l i l l i l l i.
Chapter 3 Hardware Setup 6 Channel, Firewire 1394 and SPDIF Modules 6CH1394 6CH audio + Game/Midi port, Firewire ( mP4S-1394 only 6CH1394 6CHG 6CH audio + Game/Midi port ( mP4S only 6CHG SuperAudio 6CH audio + SPDIF ( Optional. The BIOS can be upgraded from a diskette with the Award Flash utility — AWDFLASH.EXE. The BIOS image file, and update utility are available from IWILL’s WEB site: support.iwill.net Enter BIOS setup program Power-on the system by either pressing the Power-On button, or by using any of the power-on features provided by the motherboard.
Chapter 4 BIOS Setup Using BIOS setup program Move to the previous field Down Move to the next field Left Move to the field on the left hand side Right Move to the field on the right hand side Quit from setup program without saving changes,or Exit from current menu page and return to main menu page. A brief description of each highlighted selection appears at the bottom of the screen. CMOS Setup Utility-Copyright(c) 1984-2001 Award Software Standard CMOS Features IWILL Smart Setting Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults. Chapter 4 BIOS Setup Date This field specifies the current date. The date format is,. Time This field specifies the current time. The time format is,.
The time is calculated based on the 24-hour (military-time) clock. Chapter 4 BIOS Setup Cylinders Set the number of cylinders for this hard disk. Heads Set the number of read/write heads Precomp Setting a value of 65535 means no hard disk Sectors Set the number of sectors per track Drive A / Drive B This field specifies the traditional type of floppy drives. Chapter 4 BIOS Setup Video Halt On l l i l l i l l i, l l l l i, l l l l i, l l Base Memory The POST (Power-On Self Test) determines the amount of base (conventional) memory installed in the system. Chapter 4 BIOS Setup Advanced BIOS Features CMOS Setup Utility-Copyright(c) 1984-2001 Award Software Advanced BIOS Features Disabled Item Help Enabled Enabled Enabled Menu Level Floppy HDD-0 Allows you to choose SCSI the VIRUS warning Enabled feature for IDE Hard Disabled Disk boot sector Enabled protection. Chapter 4 BIOS Setup First / Secondary / Third / Boot Other Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. Floppy, LS120, HDD-0, SCSI, CDROM, HDD-1, HDD-2, HDD-3, ZIP100, LAN, Disabled Swap Floppy Drive When enabled, floppy drives A and B will be exchanged without the user physically changing the connection on the cable.
I Will P4se2 Sound Driver For Macbook Pro
Chapter 4 BIOS Setup Typematic Rate (Chars/Sec) When Typematic Rate Setting enabled, this field specifies how many characters will be displayed in one second when a key is held down continuously. 6(Default Value)8,10,12,15,20,24,30 Typematic Delay (Msec) When enabled, typematic delay allows you to select the time delay between when the key is first pressed and when the acceleration begins. Chapter 4 BIOS Setup Advanced Chipset Features This setup page is used to specify advanced features available through the chipset. The default settings have been chosen carefully for most operating conditions. DO NOT change the value of any field in this setup page without full understanding.
Chapter 4 BIOS Setup DRAM RAS# to CAS# Delay This controls the number of clocks between the SDRAM active command and the read / write command. 2,3(Default Value) DRAM RAS# Precharge If an insufficient number of cycles is allowed for the RAS to accumulate its charge before DRAM refresh, the refresh may be incomplete and the DRAM may fail to retain data. Chapter 4 BIOS Setup Integrated Peripherals CMOS Setup Utility-Copyright(c) 1984-2001 Award Software Integrated Peripherals Enabled On-C hip Primary PCI IDE Item H elp Enabled On-Chip Secondary PCI IDE Auto IDE Primary M aster M enu Level Auto IDE Primary S lave Auto IDE Secondary Master PIO Auto. Chapter 4 BIOS Setup On-Chip primary/Secondary PCI IDE This field enables or disables the onboard IDE controller. Enable(Default Value), Disabled IDE Primary Master / Slave PIO IDE Secondary Master / Slave PIO These fields configure the PIO (Programmable Input Output) transfer mode for each IDE devices. Chapter 4 BIOS Setup IDE HDD Block Mode When enabled, the IDE controller will use the faster block mode to access devices.
Enable(Default Value), Disabled Power-On Function This field configures the Power-On mode of the system. The Power-On button will not function in this mode. Chapter 4 BIOS Setup Hot Key Power-On This field specifies key selection for the Keyboard-Power On hot key.
Ctrl-F1,Ctrl-F2,Ctrl-F3,Ctrl-F4,Ctrl-F5,Ctrl-F6,Ctrl-F7,Ctrl- F8,Ctrl-F9, Ctrl-F10,Ctrl-F11,Ctrl-F12 Onboard FDC Controller This field enables or disables the onboard floppy controller. Enable(Default Value),Disabled Onboard Serial Port 1 / 2 These fields configure the onboard serial ports. Chapter 4 BIOS Setup UR2 Duplex Mode Full,Half(Default Value) Use IR Pins RxD2,TxD2,IR-Rx2Tx2(Default Value) Onboard Parallel Port This field configures the onboard parallel port. There are several port addresses and IRQ channels to select from.
Parallel Port Mode This field configures the operating mode of an onboard parallel port. Chapter 4 BIOS Setup Power Management Setup CMOS Setup Utility-Copyright(c) 1984-2001 Award Software Power Management Setup Power Management User Define Item Help Video Off Method V /H SYNC+Blank Video Off In Suspend Yes Menu Level Suspend Type Stop Grant MODEM Use IRQ 3 APM Suspend Timer Disabled.
Chapter 4 BIOS Setup Video off Method c i t. Y l i t i n i l Video Off In Suspend This determines the manner in which the monitor is blanked. NO,Yes(Default Value) Suspend Type Select the Suspend Type.
PwrOn Suspend, Stop Grant (Default Value) MODEM Use IRQ This determines the IRQ in which the MODEM can use. Chapter 4 BIOS Setup Wake up by PCI card Enabled, Disabled(Default Value) Wake up by RING/LAN When Wake up by LAN function is enabled, the PC can power-on or “wake up” through LAN (Local Area Network).
When Wake up by RING function is enabled, the PC can power-on through an external modem connected to your PC. Chapter 4 BIOS Setup Primary IDE 1 If enabled, timer restarts whenever the slave disk of the primary IDE channel is active.
Enabled, Disabled (Default Value) Secondary IDE 0 If enabled, timer restarts whenever the master disk of the secondary IDE channel is active. Enabled, Disabled (Default Value) Secondary IDE 1 If enabled, timer restarts whenever the slave disk of the.
Chapter 4 BIOS Setup PnP/ PCI Configurations CMOS Setup Utility-Copyright(c) 1984-2001 Award Software PnP/PCI Configurations PNP OS Installed No Item Help Reset Configuration Data Disabled Menu Level Resources Controlled By Auto (ESCD) x IRQ Resources Press Enter Select Yes if you are x Memory Resources Press Enter using a Plug and Play. Chapter 4 BIOS Setup Resources Controlled By The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows98/95/ NT. THE CPU IS Item Help THE CPU ID IS THE CPU EXPECT SPEED IS Menu Level CPU Micro Code Updated to Spread Spectrum =.= IWILL Micro Stepping =.= CPU Clock CPU Clock Ratio DRAM Clock CPU Vcore Setting BIOS-ROM Flash Protect. Chapter 4 BIOS Setup IWILL MicroStepping MicroStepping Microstepping is Iwill's another step forward to provides users a fuss free CPU frequency set up procedure. It contains two main functions, Auto Detecting CPUs speed and Micro Adjustable CPU FSB speed. Auto Detecting CPU speed: IWILL MicroStepping will auto detect the CPU's factory multiplier setting and CPU FSB to the factory default.
Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance system operations. CMOS Setup Utility-Copyright(c) 1984-2001 Award Software Standard CMOS Features IWILL Smart Setting Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features. Chapter 4 BIOS Setup Set Supervisor/ User Password Setting CMOS Setup Utility-Copyright(c) 1984-2001 Award Software Standard CMOS Features IWILL Smart Setting Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup. BIOS Setup Save & Exit Setup Saves current CMOS value and exit BIOS setup program. CMOS Setup Utility-Copyright(c) 1984-2001 Award Software Standard CMOS Features IWILL Smart Setting Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals. Chapter 5 On board Audio On board Audio Audio Features Special Feature 1. Full-duplex playback and recording.
Built-in 16-bit CODEC. HRTF 3D positional audio, supporting both DirectSound 3D&A3D interfaces. Also supports earphones, 2/4/6 channel speakers mode.
Support Windows 98/Windows 2000 and Windows NT 4.0. 4.Built-in 32 OHM Earphone buffer. Chapter 5 On board Audio Stereo Mixer 1. Stereo analog mixing from CD-Audio and Line-in 2. Stereo digital mixing from Voice, FM/Wave-table, and Digital CD-Audio 3. Mono mixing from MIC. Software adjustable volume.
Game and Midi Interface Fully compatible with MPU-401 Midi UART and Sound Blaster Midi mode/Standard IBM PC joystick/game port. Chapter 5 On board Audio IWILL 6Channels Audio/ SuperAudio (Optional) Connectors and Jumpers f i l JP10 function BASSl Center channel Center channel BASS channel exChange Default (BASS/Center) Channel 6Channels Audio Front-Speaker Line-IN Game/MIDI 6CH-Audio Rear-Speaker MIC-IN Center/BASS Audio Cable. Chapter 5 On board Audio SuperAudio(Optional) Front-Speaker SuperA udio Line-IN Game/MIDI Rear-Speaker MIC-IN Center/BASS RCA SPDIF OUT RCA SPDIF IN Optical SPDIF OUT Au d io Ca b l e Optical SPDIF IN IWILL 6Channels Audio IWILL SuperAudio (Optional). Chapter 5 On board Audio Driver Installation DOS Installation Before beginning the installation, please make sure that your hard disk has sufficient space(min. Insert the Power Installer CD into the CD-ROM Drive.
Change directory to PCI audio DOS drivers folder (ex. Chapter 5 On board Audio Windows NT4.0 Installation We recommend that you have Microsoft Windows NT intalled, and remove any exsisting sound drivers from your current system, before you install this PCI sound device driver. Click “Start”, move the highlight bar to “Setting”, and select the “Control Panel”. Chapter 5 On board Audio The Audio Rack Introduction By means of a user-friendly interface (as easy as operating your home stereo system), this PCI audio rack provides you with the control over your PC’s audio functions, including the advantage of six speakers mode enable/ disable, and perfect digital sound ( SPDIF version ONLY) input / output.
Chapter 5 On board Audio Mixer Volume Control For each output signal, the control slider regulates the loudness whereas a horizontal slider the balance between the two speakers. The mute button can temporarily stop the output without changing slider positions. A button with a lit LED means the output is available, and vice versa.
Chapter 5 On board Audio Advanced - SPDIF SPDIF dialog provides a full control over SPDIF IN/OUT functions. You can use these settings to connect your computer to other pieces of au- dio device, such as: Mini Disc players, amplifiersetc. Advanced - Speakers Speakers dialog provides an interface allowing you to set your speakers configurations.
Chapter 5 On board Audio Advanced - Sound effects Sound effects dialog allows you to modify the special effects of the song and game being played. Currently, these effectors can only be used for the player or the game which utilizes DirectSound 2D and 3D to playback their music.
